Blogs

Marc Rayman

Dawn Journal: Ceres Orbit Insertion!

Posted by Marc Rayman

06-03-2015 10:32 CST

Topics: mission status, asteroids, Dawn, asteroid 1 Ceres

Dear Unprecedawnted Readers,

Since its discovery in 1801, Ceres has been known as a planet, then as an asteroid, and later as a dwarf planet. Now, after a journey of 3.1 billion miles (4.9 billion kilometers) and 7.5 years, Dawn calls it “home.”

Earth’s robotic emissary arrived at about 4:39 a.m. PST today. It will remain in residence at the alien world for the rest of its operational life, and long, long after.

Before we delve into this unprecedented milestone in the exploration of space, let’s recall that even before reaching orbit, Dawn started taking pictures of its new home. Last month we presented the updated schedule for photography. Each activity to acquire images (as well as visible spectra and infrared spectra) has executed smoothly and provided us with exciting and tantalizing new perspectives.

While there are countless questions about Ceres, the most popular now seems to be what the bright spots are. It is impossible not to be mesmerized by what appear to be glowing beacons, shining out across the cosmic seas from the uncharted lands ahead. But the answer hasn’t changed: we don’t know. There are many intriguing speculations, but we need more data, and Dawn will take photos and myriad other measurements as it spirals closer and closer during the year. For now, we simply know too little.

Ceres rotation during RC2

NASA / JPL-Caltech / UCLA / MPS / DLR / IDA

Ceres rotation during RC2
Dawn observed Ceres for a full rotation of the dwarf planet, which lasts about nine hours. The photos were taken on Feb. 19 from a distance of about 28,000 miles (46,000 kilometers). A single mosaic made from the individual pictures is below. The imaging session was known as RC2.

For example, some people ask if those spots might be lights from an alien city. That’s ridiculous! At this early stage, how could Dawn determine what kinds of groupings Cereans live in? Do they even have cities? For all we know, they may live only in rural communities, or perhaps they only have large states.

What we already know is that in more than 57 years of space exploration, Dawn is now the only spacecraft ever to orbit two extraterrestrial destinations. A true interplanetary spaceship, Dawn left Earth in Sep. 2007 and traveled on its own independent course through the solar system. It flew past Mars in Feb. 2009, robbing the red planet of some of its own orbital energy around the sun. In July 2011, the ship entered orbit around the giant protoplanet Vesta, the second most massive object in the main asteroid belt between Mars and Jupiter. (By the way, Dawn’s arrival at Vesta was exactly one Vestan year ago earlier this week.) It conducted a spectacular exploration of that fascinating world, showing it to be more closely related to the terrestrial planets (including Earth, home to many of our readers) than to the typical objects people think of as asteroids. After 14 months of intensive operations at Vesta, Dawn climbed out of orbit in Sep. 2012, resuming its interplanetary voyage. Today it arrived at its final destination, Ceres, the largest object between the sun and Pluto that had not previously been visited by a spacecraft. (Fortunately, New Horizons is soon to fly by Pluto. We are in for a great year!)

What was the scene like at JPL for Dawn’s historic achievement? It’s easy to imagine the typical setting in mission control. The tension is overwhelming. Will it succeed or will it fail? Anxious people watch their screens, monitoring telemetry carefully, frustrated that there is nothing more they can do now. Nervously biting their nails, they are thinking of each crucial step, any one of which might doom the mission to failure. At the same time, the spacecraft is executing a bone-rattling, whiplash-inducing burn of its main engine to drop into orbit. When the good news finally arrives that orbit is achieved, the room erupts! People jump up and down, punch the air, shout, tweet, cry, hug and feel the tremendous relief of overcoming a huge risk. You can imagine all that, but that’s not what happened.

If you had been in Dawn mission control, the scene would have been different. You would mostly be in the dark. (For your future reference, the light switches are to the left of the door.) The computer displays would be off, and most of the illumination would be from the digital clock and the string of decorative blue lights that indicate the ion engine is scheduled to be thrusting. You also would be alone (at least until JPL Security arrived to escort you away, because you were not cleared to enter the room, and, for that matter, how did you get past the electronic locks?). Meanwhile, most of the members of the flight team were at home and asleep! (Your correspondent was too, rare though that is. When Dawn entered orbit around Vesta, he was dancing. Ceres’ arrival happened to be at a time less conducive to consciousness.)

Why was such a significant event treated with somnolence? It is because Dawn has a unique way of entering orbit, which is connected with the nature of the journey itself. We have discussed some aspects of getting into orbit before (with this update to the nature of the approach trajectory). Let’s review some of it here.

It may be surprising that prior to Dawn, no spacecraft had even attempted to orbit two distant targets. Who wouldn’t want to study two alien worlds in detail, rather than, as previous missions, either fly by one or more for brief encounters or orbit only one? A mission like Dawn’s is an obvious kind to undertake. It happens in science fiction often:  go somewhere, do whatever you need to do there (e.g., beat someone up or make out with someone) and then boldly go somewhere else. However, science fact is not always as easy as science fiction. Such missions are far, far beyond the capability of conventional propulsion.

Deep Space 1 (DS1) blazed a new trail with its successful testing of ion propulsion, which provides 10 times the efficiency of standard propulsion, showing on an operational interplanetary mission that the advanced technology really does work as expected. (This writer was fortunate enough to work on DS1, and he even documented the mission in a series of increasingly wordy blogs. But he first heard of ion propulsion from the succinct Mr. Spock and subsequently followed its use by the less logical Darth Vader.)

Dawn's first map of Ceres

NASA / JPL-Caltech / MPS / DLR / IDA

Dawn's first map of Ceres
Dawn observed Ceres throughout a full nine-hour rotation of the dwarf planet, yielding this global mosaic of craters, mysterious bright spots and other intriguing features. The photos were taken on Feb. 19 from a distance of about 28,000 miles (46,000 kilometers) during imaging session RC2.

Dawn’s ambitious expedition would be truly impossible without ion propulsion. (For a comparison of chemical and ion propulsion for entering orbit around Mars, an easier destination to reach than either Vesta or Ceres, visit this earlier log.) So far, our advanced spacecraft has changed its own velocity by 23,800 mph (38,400 kilometers per hour) since separating from its rocket, far in excess of what any other mission has achieved propulsively. (The previous record was held by DS1.)

Dawn is exceptionally frugal in its use of xenon propellant. In this phase of the mission, the engine expends only a quarter of a pound (120 grams) per day, or the equivalent of about 2.5 fluid ounces (75 milliliters) per day. So although the thrust is very efficient, it is also very gentle. If you hold a single sheet of paper in your hand, it will push on your hand harder than the ion engine pushes on the spacecraft at maximum thrust. At today’s throttle level, it would take the distant explorer almost 11 days to accelerate from zero to 60 mph (97 kilometers per hour). That may not evoke the concept of a drag racer. But in the zero-gravity, frictionless conditions of spaceflight, the effect of this whisper-like thrust can build up. Instead of thrusting for 11 days, if we thrust for a month, or a year, or as Dawn already has, for more than five years, we can achieve fantastically high velocity. Ion propulsion delivers acceleration with patience.

Most spacecraft coast most of the time, following their repetitive orbits like planets do. They may use the main engine for a few minutes or perhaps an hour or two throughout the entire mission. With ion propulsion, in contrast, the spacecraft may spend most of its time in powered flight. Dawn has flown for 69% of its time in space emitting a cool blue-green glow from one of its ion engines. (With three ion engines, Dawn outdoes the Star Wars TIE — twin ion engine — fighters.)

Crescent Ceres

NASA / JPL-Caltech / UCLA / MPS / DLR / IDA

Crescent Ceres
As Dawn maneuvers into orbit, its trajectory takes it to the opposite side of Ceres from the sun, providing these crescent views. These pictures (part of the OpNav 5 activity), were taken on March 1 at a distance of 30,000 miles (49,000 kilometers).

The robotic probe uses its gentle thrust to gradually reshape its path through space rather than simply following the natural course that a planet would. After it escaped from Vesta’s gravitational clutches, it slowly spiraled outward from the sun, climbing the solar system hill, making its heliocentric orbit more and more and more like Ceres’. By the time it was in the vicinity of the dwarf planet today, both were traveling around the sun at more than 38,600 mph (62,100 kilometers per hour). Their trajectories were nearly identical, however, so the difference in their speeds was only 100 mph (160 kilometers per hour), or less than 0.3 percent of the total. Flying like a crackerjack spaceship pilot, Dawn elegantly used the light touch of its ion engine to be at a position and velocity that it could ease gracefully into orbit. At a distance of 37,700 miles (60,600 kilometers), Ceres reached out and tenderly took the newcomer from Earth into its permanent gravitational embrace.

If you had been in space watching the event, you would have been cold, hungry and hypoxic. But it would not have looked much different from the 1,885 days of ion thrust that had preceded it. The spacecraft was perched atop its blue-green pillar of xenon ions, patiently changing its course, as it does for so much of quiet cruise. But now, at one moment it was flying too fast for Ceres’ gravity to hang on to it, and the next moment it had slowed just enough that it was in orbit. Had it stopped thrusting at that point, it would have continued circling the dwarf planet. But it did not stop. Instead, it is working now to reshape its orbit around Ceres. As we saw in November, its orbital acrobatics first will take it up to an altitude of 47,000 miles (75,000 kilometers) on March 19 before it swoops down to 8,400 miles (13,500 kilometers) on April 23 to begin its intensive observations in the orbit designated RC3.

In fact, Dawn’s arrival today really is simply a consequence of the route it is taking to reach that lower orbit next month. Navigators did not aim for arriving today. Rather, they plotted a course that began at Vesta and goes to RC3 (with a new design along the way), and it happens that the conditions for capture into orbit occurred this morning. As promised last month, we present here a different view of the skillful maneuvering by this veteran space traveler.

NASA / JPL-Caltech

Dawn Ceres Trajectory
This animation gives a three-dimensional view of Dawn’s complex approach to Ceres. The spacecraft deftly maneuvers into orbit with its ion propulsion system, flying to RC3 orbit, which is achieved when the thrust is turned off. (The size of Ceres is exaggerated compared to the size of the orbit here.) At the end, the viewpoint shifts to provide another perspective on the unique trajectory.

If Dawn had stopped thrusting before Ceres could exert its gravitational control, it wouldn’t have flown very far away. The spacecraft had already made their paths around the sun very similar, and the ion propulsion system provides such exceptional flexibility to the mission that controllers could have guided it into orbit some other time. This was not a one-time, all-or-nothing event.

So the flight team was not tense. They had no need to observe it or make a spectacle out of it. Mission control remained quiet. The drama is not in whether the mission will succeed or fail, in whether a single glitch could cause a catastrophic loss, in whether even a tiny mistake could spell doom. Rather, the drama is in the opportunity to unveil the wonderful secrets of a fascinating relict from the dawn of the solar system more than 4.5 billion years ago, a celestial orb that has beckoned for more than two centuries, the first dwarf planet discovered.

Dawn usually flies with its radio transmitter turned off (devoting its electricity instead to the power-hungry ion engine), and so it entered orbit silently. As it happened, a routine telecommunications session was scheduled about an hour after attaining orbit, at 5:36 a.m. PST. (It’s only coincidence it was that soon. At Vesta, it was more than 25 hours between arrival and the next radio contact.) For primary communications, Dawn pauses thrusting to point its main antenna to Earth, but other times, as in this case, it is programmed to use one of its auxiliary antennas to transmit a weaker signal without stopping its engine, whispering just enough for engineers to verify that it remains healthy.

The Deep Space Network’s exquisitely sensitive 230-foot (70-meter) diameter antenna in Goldstone, Calif., picked up the faint signal from across the solar system on schedule and relayed it to Dawn mission control. One person was in the room (and yes, he was cleared to enter). He works with the antenna operator to ensure the communications session goes smoothly, and he is always ready to contact others on the flight team if any anomalies arise. In this case, none did, and it was a quiet morning as usual. The mission director checked in with him shortly after the data started to trickle in, and they had a friendly, casual conversation that included discussing some of the telemetry that indicated the spacecraft was still performing its routine ion thrusting. The determination that Dawn was in orbit was that simple. Confirming that it was following its flight plan was all that was needed to know it had entered orbit. This beautifully choreographed celestial dance is now a pas de deux.

As casual and tranquil as all that sounds, and as logical and systematic as the whole process is, the reality is that the mission director was excited. There was no visible hoopla, no audible fanfare, but the experience was powerful fuel for the passionate fires that burn within.

As soundlessly as a spacecraft gliding through the void, the realization emerges...

Dawn made it!!

It is in orbit around a distant world!!

Yes, it’s clear from the technical details, but it is more intensely reflected in the silent pounding of a heart that has spent a lifetime yearning to know the cosmos. Years and years of hard work devoted to this grand undertaking, constant hopes and dreams and fears of all possible futures, uncounted challenges (some initially appearing insurmountable) and a seeming infinitude of decisions along the way from early concepts through a real interplanetary spacecraft flying on an ion beam beyond the sun.

And then, a short, relaxed chat over a few bits of routine data that report the same conditions as usual on the distant robot. But today they mean something different.

They mean we did it!!

Everyone on the team will experience the news that comes in a congratulatory email in their own way, in the silence and privacy of their own thoughts. But it means the same to everyone.

We did it!!

And it’s not only the flight team. Humankind!! With our relentless curiosity, our insatiable hunger for knowledge, our noble spirit of adventure, we all share in the experience of reaching out from our humble home to the stars.

Together, we did it!!!

It was a good way to begin the day. It was Dawn at Ceres.

(This video overview of the mission at Ceres is a great way to start your day, but you can enjoy it at any time.)

Let’s bring into perspective the cosmic landscape on which this remarkable adventure is now taking place. Imagine Earth reduced to the size of a soccer ball. On this scale, the International Space Station would orbit at an altitude of a bit more than one-quarter of an inch (seven millimeters). The moon would be a billiard ball almost 21 feet (6.4 meters) away. The sun, the conductor of the solar system orchestra, would be 79 feet (24 meters) across at a distance of 1.6 miles (2.6 kilometers). But even more remote, Dawn would be 5.3 miles (8.6 kilometers) away. (Just a few months ago, when the spacecraft was on the opposite side of the sun from Earth, it would have been more than six miles, or almost 10 kilometers, from from the soccer ball.) Tremendously far now from its erstwhile home, it would be only a little over a yard (a meter) from its new residence. (By the end of this year, Dawn will be slightly closer to it than the space station is to Earth, a quarter of an inch, or six millimeters.) That distant world, Ceres, the largest object between Mars and Jupiter, would be five-eighths of an inch (1.6 centimeters) across, about the size of a grape. Of course a grape has a higher water content than Ceres, but we can be sure that exploring this intriguing world of rock and ice will be much sweeter!

As part of getting to know its new neighborhood, Dawn has been hunting for moons of Ceres. Telescopic studies had not revealed any, but if there were a moon smaller than about half a mile (one kilometer), it probably would not have been discovered. The spacecraft’s unique vantage point provides an opportunity to look for any that might have escaped detection. Many pictures have been taken specifically for this purpose, and scientists scrutinize them and all of the other photographs for any indication of moons. While the search will continue, so far, no picture has shown evidence of companions orbiting Ceres.

And yet we know that as of today, Ceres most certainly does have one. Its name is Dawn!

Dawn is 37,800 miles (60,800 kilometers) from Ceres, or 16 percent of the average distance between Earth and the moon. It is also 3.33 AU (310 million miles, or 498 million kilometers) from Earth, or 1,230 times as far as the moon and 3.36 times as far as the sun today. Radio signals, traveling at the universal limit of the speed of light, take 55 minutes to make the round trip.

Dr. Marc D. Rayman
6:00 a.m. PST March 6, 2015


See other posts from March 2015



Or read more blog entries about: mission status, asteroids, Dawn, asteroid 1 Ceres

Comments:

RLee: 03/06/2015 06:25 CST

In para 4, you say "It is impossible not to be mesmerized by what appear to be reatlowing beacons, shining out across the cosmic seas from the uncharted lands ahead." I cannot figure out what is meant by "reatlowing", or what word might have been intended instead.

Messy: 03/07/2015 07:58 CST

thanks for the "special edition"!!!!

Marc Rayman: 03/07/2015 08:45 CST

RLee, I cannot figure it out either! I wrote "glowing." It appears that when this was posted on the Dawn website, a glitch was introduced, and so it shows up here. I've asked that it be corrected there, and I'm sure it will be updated here soon as well. Thank you for pointing it out.

Jonathan Ursin: 03/07/2015 09:59 CST

If Dawns' instruments are unable to figure out what the great white spot is then we'll have to send a lander. My newest guess is the spot is a piece of rock from an impact. Most of it blew up into tiny pieces but two large pieces, and maybe more smaller ones yet to be discovered remain.

Bob Ware: 03/07/2015 01:09 CST

Congratulations! I only had Cheeri-O's for breakfast. That was just as good! My guess for the bright spots would be newly uncovered ices most likely by venting or small impact that led to the vapor "cloud" being detected. Maybe time will tell.

David: 03/08/2015 05:26 CDT

I suspect that "reatlowing" was a failed edit of great > glowing, or perhaps the other way around. I can't imagine the source of the reflection could just be "a piece of rock." Even if it were made of pure untarnished silver or other shiny metal, the roughness of any substance in its natural state (and particularly if broken by impact) would limit its reflectivity; reflected light would be sent in many different directions from a jagged surface. For this amount of brightness I would expect the reflection to be specular, implying a smooth, flat surface to send back the light in a single direction.

Andrew R Brown: 03/09/2015 04:46 CDT

I suspect the bright spot is certainly the central peak of a crater. In fact, the reason for it being so bright is certainly the central mountain has steep sides, allowing for regular landslides to keep it ‘clean’ from space weathering. Also I suspect the other bright spot to the east in the same crater to be a very recent landslide on the crater wall. Cryovolcanism is certainly not happening as 1 Ceres lacks both tidal heating and internal radioactive heating. The very tenuous vapour is just sublimation. Andrew R Brown.

David: 03/10/2015 02:14 CDT

I don't think we know enough about Ceres' internal conditions. And while the images of Ceres' rotation seem to show that the reflective source is elevated, I can't think of any other example where a central crater peak (of which there are many in the solar system) glows like that. Furthermore there are *two* spots. Another possibility might be that some sort of gas is being continuously emitted from Ceres' interior, forming a bright, reflective cloud over the points of outgassing, but quickly dissipating as it spreads further away from the source. We'll know in a few weeks!
