Larry Crumpler

Field Report From Mars: Sol 3431 - September 18, 2013

Posted by Larry Crumpler

2013/09/18 11:27 CDT

Topics: Opportunity, mission status, Mars Exploration Rovers, Mars

• Opportunity "wades ashore" at Solander Point on September 13

• Climbing Solander Point is imminent

• Spectacular Navcam panorama of the major geologic contact at this location

On sol 3425 Opportunity "waded ashore" at Solander Point after crossing a sea of sand between here and Cape York. Cape York was an "island" remnant of the rim of Endeavour crater that Opportunity left back in May. Since then it has been driving south to the next largest and mountainous remnant of the crater rim, Solander Point. The sand surrounds the isolated remnants of the rim of Endeavour crater and both Cape York and Solander Point are small exposures of very ancient terrain nearly engulfed by the later sands of Merdiani Planum.

In the last few weeks we have been "sailing" northwest along the "east coast" of Solander Point looking at an odd escarpment along its east edge. But finally on September 13, Opportunity landed on the bed rock of Solander Point. The rest of this week we have spent walking across the tip of Solander Point to get to the bright outcrops on the west side.

This morning we arrived at that outcrop where Opportunity will spent the weekend doing detailed analysis before moving on. Currently the solar power is getting less as late fall approaches on Mars. So Opportunity needs to start the climb along the ridge of Solander Point where the northerly slopes will yield more power and science activities may continue in the coming months.

The big goal is 200 meters south, but the terrain right here on sol 3431 is awesome. There are several geologic units that are overlapping here. And Opportunity is sitting on the contact. On the east side of the contact are rocks maybe a billion years older than those on the west side of the contact. This sort of age progression is what geologists look for when trying to understand the past by reading the rocks. Opportunity is allowing us for the first time to do not only fundamental geographic exploration, but it is enabling on-the-ground geologic study of past climatic history on Mars. You only get to do that once per planet. We are here. And we are doing it now, this weekend.

Opportunity Navcam mosaic of Solander Point

NASA/JPL-Caltech

Opportunity Navcam mosaic of Solander Point

In this historic perspective you can see the "shoreline" where the younger, lighter toned sandstone laps up onto the low cliffs of much older bedrock on the "island" of Solander Point. This Navcam panorama was taken on September 12 just before Opportunity made "landfall." In the distance in the background is the ridge line that Opportunity will be climbing in the coming months.

Opportunity sol 3375 Pancam panorama, approaching Solander Point

NASA/JPL-Caltech/Cornell/Larry Crumpler

Opportunity sol 3375 Pancam panorama, approaching Solander Point

Above is the Pancam panorama we acquired on sol 3375 when Opportunity was still approaching Solander Point. On it I have plotted the subsequent drives along the east side of the point, and the location on the contact as of September 18. The approximate places were we need to be by later this fall are shown here for anyone following along. It's a new unexplored land with new scenes.

HiRISE view of Opportunity's recent path to Solander Point

NASA/JPL-Caltech/University of Arizona/Larry Crumpler

HiRISE view of Opportunity's recent path to Solander Point

Above is the corresponding overhead view using the Mars Reconnaissance Orbiter HiRISE camera view as a base. You can see how Opportunity has spent the last couple of sols walking across the very northernmost tip of Solander Point.

Opportunity Navcam mosaic, sol 3431

NASA/JPL-Caltech

Opportunity Navcam mosaic, sol 3431

In the above Navcam panorama acquired on mid-morning on September 18 (sol 3431), you can see the contact between the younger Burns Formation sulfate-rich sands on the right and the older rocks of Endeavour crater on the left. We will probably follow this contact for ways to the south before starting the climb next week.



Or read more blog entries about: Opportunity, mission status, Mars Exploration Rovers, Mars

Comments:

Paul McCarthy: 09/19/2013 02:54 CDT

You can feel the crunching beneath your boots, and the need to climb the hill south to see what's in the bright (hydrated?) outcrops. Truly amazing.

Bob Ware: 09/21/2013 11:40 CDT

The MRO image clearly shows this to be an interesting piece of geologic structure...at least to me!
