Headshot of Emily Lakdawalla

Titan crater and programming note

Posted by Emily Lakdawalla

02-09-2011 11:58 CDT

Topics: pretty pictures, Cassini, Titan, Saturn's moons, radar imaging

The summer is winding to a close but it's not quite over for me -- by which I mean my children -- yet. They're at home with me for a few days until school picks up again on Wednesday next week. All the holidays and travel of the summer have left me with an enormous backlog of space stories to tell, not to mention the stories that guest bloggers want to tell, nor to mention the hundreds of unread(!) messages in my mailbox, unopened academic journals, unexplored image releases, and un-transcribed notes from the New Horizons science meeting. This is just a note to explain that I may be scarce for a few days on the blog and Twitter for this last week or so of summer, and then it will be time for me to begin digging myself out with lots of cool things to show and tell you!

In the meantime, please enjoy this new discovery from Titan, the eighth known impact crater, accompanied by a wonderfully thorough caption written by a member of the Cassini RADAR team.

Newly discovered crater on Titan

NASA / JPL-Caltech

Newly discovered crater on Titan
Impact craters are rare on Titan. Until recently only seven had been identified definitely on Titan, so it was exciting when Cassini's Titan Radar Mapper imaged an eighth impact crater on June 21, 2011. This newly discovered crater is about 25 miles (40 kilometers) in diameter and is surrounded by a continuous blanket of ejecta (material thrown out from the crater) that appears bright to radar and extends roughly 10 to 12 miles (15 to 20 kilometers) beyond the rim. With its well-preserved ejecta and steep inward-facing walls, the new crater resembles the two other freshest known craters on Titan: Sinlap, seen in the radar image of February 2005 (PIA07368), and Ksa, seen in September 2006 (PIA08737) and imaged again in this latest flyby. One difference is that Sinlap and the new crater seem to have flat, largely featureless floors, but Ksa has a bright central peak.

Dunes, visible as dark lines on the left of the image, have been swept toward the crater by the winds of Titan. These dunes have encroached very little onto the bright ejecta, compared to those on Ksa where more than a third of the ejecta blanket on its western edge is covered by dunes.

While Saturn's other moons have many thousands of craters, Titan has very few. One reason is that Titan's dense atmosphere burns up the smaller impacting bodies before they can reach the surface. The craters that do form are often hard to recognize or disappear entirely as they are eroded over time by geological processes such as the wind-driven motion of sand and, possibly, icy volcanism.

This synthetic-aperture radar (SAR) image, centered at 12 degrees north latitude and 45 degrees west longitude, measures 150 miles (242 kilometers) high by 160 miles (257 kilometers) wide, with resolution of about 350 meters per pixel; north is at the top, and the image is illuminated from the bottom. Incidence angle varies from 15 to 25 degrees.
See other posts from September 2011


Or read more blog entries about: pretty pictures, Cassini, Titan, Saturn's moons, radar imaging
