Headshot of Emily Lakdawalla

Pretty picture: Three moons of Saturn

Posted by Emily Lakdawalla

29-10-2010 24:08 CDT


The Cassini Raw Images Website always offers rewards to the browser. This evening I found the raw images necessary to create this color composite, showing the hazy orange moon Titan, the mid-sized icy moon Dione, and the tiny rock Prometheus all at the same time. (Prometheus may be a little hard to spot, a tiny oblate thing sitting on top of the faint line of the F ring at upper left corner.)

Titan, Dione, rings, Prometheus

NASA / JPL / SSI / color composite by Emily Lakdawalla

Titan, Dione, rings, Prometheus
Cassini captured the three images for this approximately true color composite on October 18, 2010. While Cassini studied Titan, the mid-sized icy moon Dione wandered through the field of view, while Prometheus sat atop the F ring at upper left.
The original images were captured through red, green, and blue filters on October 18, while Titan was more than 2.5 million kilometers away from the Cassini orbiter. Dione was shooting through the field of view rather quickly, and Prometheus even faster; in fact, Prometheus was well gone by the time that the blue-filter image was taken, so I had to fake it with a piece of the green-filter image. Everything in the image had to be aligned slightly differently -- Titan, Dione, Prometheus and its related chunk of F ring, and the tiny sliver of the main rings at upper left corner.

A few posts ago there were a lot of people clamoring to explain why I have to do so much work in Photoshop to make Cassini images pretty, so I'll show you what this set of pictures would look like as a color composite without all the Photoshop work; this is just a straight color combination of the three raw photos, with the red-filter image in the red channel, green-filter image in the green channel, and blue-filter image in the blue channel.

A Cassini color image without alignment

NASA / JPL / SSI / color composite by Emily Lakdawalla

A Cassini color image without alignment
Three images taken through red, green, and blue filters on October 18, 2010 were combined into a color composite without any alignment of the individual images. The most obvious problem is with Dione, which clearly moved between red, green, and blue filters, but if you look at upper left you can see the tiny potato shape of Prometheus showing up in only red and green filters and absent entirely from the blue filter image. Less obvious are color channel misalignments among the rings and on Titan; the blue channel is shifted several pixels upward with respect to the red and green channels, resulting in a blue halo above Titan and the rings and a yellow and green halo below them.
Hopefully most of you agree that the top version of the image is an improvement!
