Voyager at Saturn, one year later

Posted By Emily Lakdawalla

2010/07/27 02:04 CDT

Topics:

Here are two newly processed portraits of Saturn, showing the planet just after its equinox; the shadows of the rings are widening in a band that is slowly moving downward across the southern hemisphere. The rings appear pretty dark, since the Sun strikes them at a very low angle.

They're newly processed images, by Gordan Ugarkovic -- but they are not new images. These are Voyager 1 and Voyager 2's departing shots of Saturn, taken on December 15, 1980 and August 29, 1981. It's been very nearly three decades since those two encounters. But we've already passed one "anniversary" that's more significant in this context. May 19, 2010, marked exactly one Saturn year since Voyager 1's flyby; January 31, 2011 will be one Saturn year since Voyager 2's flyby. Thus the portraits of Saturn that Cassini is getting right now (like, for instance, this one) see the planet in the same season, with the ring shadows in the same place, and the same contrast in appearance between bright planet and dark rings, as the Voyagers saw.

NASA / JPL / color composite by Gordan Ugarkovic

Voyager 1's departure shot of Saturn

Saturn was Voyager 1's last planetary encounter. It captured this iconic image of the ringed giant as it left the Saturn system at 21:15 UTC on December 15, 1980. Unlike its twin Voyager 2's departing view, Voyager 1 looked down onto the lit side of the rings; but since Saturn had just passed through its equinox, the Sun was not far above the ring plane, and the rings appeared dark. This is a newly reprocessed version created by Gordan Ugarkovic using green, blue, and violet filter images processed to resemble natural color.

NASA / JPL / color composite by Gordan Ugarkovic

Voyager 2's departure shot of Saturn

After Voyager 2 zipped by Saturn it looked back to catch a departing portrait of the ringed planet. This view was taken with Voyager's wide-angle camera on August 29, 1981 at 03:45 UTC. This is a newly reprocessed version by Gordan Ugarkovic, using orange, green, blue, violet, and clear filter images. The view is onto the southern hemisphere and the unlit side of Saturn's rings -- much like Cassini's view at the end of 2010.

At low resolution, the images do look very similar to Cassini's. Zoom in to see the high-res versions, and it's possible you'll feel a bit of disappointment. The images are so grainy, with lots and lots of random noise, especially in the darkest areas. It's impossible to see the F ring, and the C ring is nearly invisible, in the iconic Voyager 1 shot. We've become so spoiled by the crispness of Cassini images; its cameras' CCD detectors are exquisitely sensitive and subject to nothing near as much dark current or other instrument artifacts as Voyager's vidicon tubes were.

Even if they are inferior to what we can see now in Cassini images, they are, of course, poignant. And it boggles the mind to think that in all the time that has passed since the Voyagers encountered Saturn, very nearly my entire lifetime, the ringed planet has completed just one journey around the Sun.
