Earth and the Moon from Mercury

Filed under pretty pictures, pics of Earth by planetary missions, Earth, the Moon, MESSENGER

Go Back

Earth and the Moon from Mercury The pair of bright star-like features in the upper panel are not stars at all, but the Earth and Moon! MESSENGER took the photo on July 19, 2013, from a distance of 98 million kilometers. Earth and Moon are both overexposed; the image was part of a long-exposure search for satellites around Mercury.

NASA / JHUAPL / CIW

The computer-generated image in the lower left shows how the Earth appeared from Mercury at the time. Much of the Americas, all of Europe and Africa, the Middle East, and much of Asia were visible.

MESSENGER took this image as part of a campaign to search for natural satellites of Mercury. Mercury has no moons that we know of. If any exist, they must be small (less than a few kilometers), or we would have seen them by now. The strategy for the satellite search involves taking multiple images of locations at predetermined distances from Mercury, from 2.5 to 25 times the planet radius. Pictures of these points in space are captured at intervals ranging from seconds to nearly an hour, depending on their distances from Mercury. A moving satellite will appear at different positions in images of the same region of space taken at different times.

The Earth and Moon appear very large in this picture because they are overexposed. When looking for potentially dim satellites, long exposures are required to capture as much light as possible. Consequently, bright objects in the field of view become saturated and appear artificially large. In fact, the Earth and Moon are each less than a pixel in size, and no details on either can be seen. The “tails” pointing downward from the Earth and Moon are artifacts caused by the image saturation. These can be seen clearly in the zoomed image in the center lower panel.

This image was taken on the same day that images with Earth in the scene were acquired by the Cassini spacecraft, as part of a mosaic of the backlit Saturn system.

One day later in the search for satellites of Mercury, MESSENGER again took similar images of the Earth and Moon. The date of those images, July 20, was the 44th anniversary of the Apollo 11 landing on the Moon. All six Apollo landing sites are illuminated in the MESSENGER images, although they cannot be resolved. Their locations are marked on the simulated image in the lower right panel.

The background for this image is the region between the constellations Sagittarius (the archer) and Scutum (the shield). The right ascension and declination of Earth are 18h 55m 44s and -18° 25' 31", respectively. Pluto is also in the field of view but far too dim to be seen.

Below is a photo taken from a GOES weather satellite that shows Earth at about the same time as the MESSENGER image was taken above. The GOES image was grayscale; it has been colorized with data from NASA's Visible Earth project using the Planetary Habitability Laboratory's Scientific Exoplanets Renderer software.

Earth at the moment of the

PHL @ UPR Arecibo, NASA/Johns Hopkins University Applied Physics Laboratory/Carnegie Institution of Washington, NERC Satellite Station, Dundee University, Scotland

Earth at the moment of the "Day the Earth Smiled" photo
Public domain

This image is in the public domain. Original image data dated on or about July 19, 2013
